Part No
90NX08L1-M005S0

Sales Model Name
B3405CCA-LY0169X

Progettato per aumentare la produttività, ASUS ExpertBook B3 è un PC AI flessibile creato per i professionisti di oggi. Dotato di processori Intel® Core™ Ultra e doppio slot SO-DIMM per una memoria DDR5 fino a 64 GB, è pronto per carichi di lavoro impegnativi. Rimani connesso ovunque con il 5G opzionale e lavora in totale affidabilità grazie alle funzionalità di sicurezza avanzate, tra cui Intel vPro®, TPM e accesso biometrico tramite sensore di impronte digitali e fotocamera IR. Il suo design termico silenzioso garantisce prestazioni senza interruzioni, mentre l'elegante design dell'ExpertBook lo rende professionale e portatile. Perfettamente su misura per flussi di lavoro più intelligenti, ovunque ti trovi.

EAN Code
4711387954355

UPC Code
197105954359

WEEE
1.108

BASE UNIT
VSNX08L1-BU4111

Operating System
Windows 11 Pro

Office
1-month trial for new Microsoft 365 customers. Credit card required.

LCD cover-material
Aluminum

LCD cover-color
Gentle Grey

Top case-material
Plastic

Top case-color
Gentle Grey

Bottom case-material
Plastic

Bottom case-color
Gentle Grey

Military grade
US MIL-STD 810H military-grade standard

Panel Size
14.0-inch

Backlit
LED Backlit

Brightness
300nits

Resolution
WUXGA (1920 x 1200) 16:10

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
170/170

Response time(Typ/Max) (ms)
20/25

Refresh rate
60Hz

Contrast (Typ)
800:1

Touch Panel
Non-touch screen

Screen-to-body ratio
84 %

Pantone
N/A

IPS-level
Wide view

Processor
Intel® Core™ Ultra 5 Processor 225H 1.7 GHz (18MB Cache, up to 4.9 GHz, 14 cores, 14 Threads)
Intel® AI Boost NPU up to 13 TOPS

Neural processor
Intel® AI Boost NPU

Chipset
N/A

Discrete/Share
Share

Integrated GPU
Intel® Graphics

How to upgrade memory
Upgradable
Need to remove bottom/top case

Expansion Slot(includes used)
2x DDR5 SO-DIMM slots
1x M.2 2230 PCIe 4.0x4
1x M.2 2280 PCIe 4.0x4
While selecting the LTE/5G specification, the 2230 SSD can’t be installed additionally due to design limitation.

On board memory
N/A

DIMM Memory
16GB DDR5 SO-DIMM

Total System Memory
DDR5 16GB

Storage
512GB M.2 2280 NVMe PCIe 4.0 SSD
SSD Housing for storage expansion

Front-facing camera
1080p FHD camera with IR function to support Windows Hello
With privacy shutter

Wireless
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth 5.4 Wireless Card

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard

I/O ports
2x USB 3.2 Gen 1 Type-A
2x USB 3.2 Gen 2 Type-C support display / power delivery
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack
1x RJ45 Gigabit Ethernet
Micro SD card reader

Audio
Audio by Dirac
Smart Amp Technology
Built-in speaker
Built-in array microphone

Battery
50WHrs, 3S1P, 3-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord)

Required charging power
Min: 55W
Max: 65W
The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.

Dimension (WxHxD)
31.51 x 22.68 x 1.89 ~ 1.90 cm (12.41" x 8.93" x 0.74" ~ 0.75")

Weight (with Battery)
1.49 kg (3.28 lbs)

Weight (w/o Battery)
1.30 kg (2.87 lbs)

Security
Fingerprint sensor integrated with Power Key
Kensington Nano Security Slot(6x 2.5mm)
BIOS Booting User Password Protection
BIOS Integrity Measurement Support
BIOS Self Recovery
BIOS setup user password
CSME BIOS Redundancy Assistance
Enhanced Password Strength
HDD User Password Protection and Security
Intel CSME Firmware Resilience
Intel® BIOS Guard
Intel® Boot Guard
Microsoft Secured-core PC
Microsoft Security Level 2
Support Absolute Persistence 2.0 (Computrace)
Trusted Platform Module (TPM) 2.0
N/A

Antivirus
McAfee 30 days free trial

MyASUS feature
System diagnosis
Battery health charging
Fan Profile
Splendid
Tru2Life
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS

Built-in Apps
AI ExpertMeet (AI features need devices with 12GB RAM or more)
MyASUS

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU
MyASUS/McAfee don't support in Pure OS/without OS/G SKU/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Reparability Index (for France)
9.9

Reparability Index (for Belgium)
9.5

Ecolabels & Compliances
EPEAT Gold with Climate+
Energy star 8.0
FSC Recycled
REACH
RoHS
TCO Certified

Base Warranty
1Y Pick up/ return
ZENCARE + 1Y Pick up/ return

Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX10-004011NX//1Y International Extention
ACX13-00699BNX//1Y Extension
3Y OnSite Service(Next Business Day)*upgrade
If you would like to know the details, please contact your sales teams.

Battery warranty
Commercial NB B series Battery warranty follow system warranty, 4Y-5Y by WEP option.

Sustainable Material_Top cover(A part)
30% PCR recycled plastic(cover or inner frame)
30% PIR recycled aluminum

Sustainable Material_Keyboard frame (C part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Bottom cover (D part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Battery
30% PCR recycled plastic

Sustainable Material_Keyboard
50% PCR recycled plastic cap

Sustainable Material_Speaker
45% PCR + 5% OBP PCR recycled plastic enclosure

Sustainable Material_Total PCR recycled plastic
29%
