Performance
Display Size: 23.8"
View Area: 527x296.5 mm
Panel: In-Plane Switching
Backlight: WLED
Aspect Ratio: 16:9
Resolution: 1920x1080
Pixel Pitch: 0.2745x0.2745 mm
Dot / Pixel Per Inch: 93 dpi
View Angle (H / V): 178° / 178°
Response Time: 4ms GtG (Extreme mode) / 6ms GtG (Typical mode)
Color Support: 16.7 Million
Refresh Rate: 48Hz - 120Hz
Brightness: 250 cd/m²
Contrast Ratio: 1500:1
Color Gamut: 99% sRGB, 99%BT.709
Screen Surface Treatment: Anti-glare
Curvature: None
Camera: Integrated webcam (5MP, IR+RGB)
Microphone: Integrated Microphone
Speakers: 5Wx2
Power Consumption (Typical / Maximum): 16W / 165W
Power Adapter: Integrated

Design
Stand: Tilt, Swivel, Pivot, Height Adjust Stand
Case Color: Eclipse Black
Side Bezel Width: 2 mm
Mounting: Supports VESA mount 100 x 100 mm
ThinkCentre M Series Support: Tiny Support
Dimensions (WxDxH):
- Lowest Position | 539.8 x 190.0 x 385.2 mm (21.25 x 7.48 x 15. inches)
- Highest Position | 539.8 x 190.0 x 540.2 mm (21.25 x 7.48 x 21.27 inches)
- Head Only | 539.8 x 50.0 x 362.7 mm (21.25 x 1.97 x 14.28 inches)
Packaging Dimensions (WxDxH): 730.0 x 111.0 x 450.0 mm (28.74 x 4.37 x 17.72 inches)
Weight:
- Monitor With Stand | 5.9 kg (13 lbs)
- Monitor Only | 3.8 kg (8.4 lbs)
Packaging Weight: 8.4 kg (18.5 lbs)

Connectivity
USB Port: 1x USB-C (USB 5Gbps, PD 3.0 100W, USB upstream), 3x USB-A (USB 5Gbps, 1x BC 1.2, USB downstream), 1x USB-C (USB 5Gbps, 15W PD, USB downstream)
Video Connector: 1x HDMI 2.1 TMDS, 1x DP 1.4 (HBR2), 1x DP 1.4 Out, 1x USB-C (DP 1.4 Alt Mode HBR2)
Network Connectivity: 1x RJ45, Ethernet (10M/100M/1000M)

Service
Base Warranty: 3-year

Certifications
Environmental Certification: ENERGY Star Certified, TCO 10, TCO Edge 2.1, EPEAT Gold, EU Energy Efficiency Level (Level-E), Volatile Organic Compound Certification, RoHS
Ergonomic Certification: Eyesafe Display 2.0, TÜV Rheinland Low Blue Light (Hardware solution), TÜV Rheinland Eye Comfort (5 Stars)
Sync Technology: None
Special Features:
- AI Feature (Smart Face Framing, Multi-person Detection, Smart Volume Control)
- Conference Indicator
- LADM (Lenovo Accessories and Display Manager)
- Lenovo Accessories and Display Manager supports Windows 10 & 11, Mac OS (functions vary across systems).
- Lenovo Accessories and Display Manager is formerly Lenovo Display Control Center.
- LDFM (Lenovo Display Fleet Manager)
- Mirrored Power Button
- Natural Low Blue Light
- Smart Power
- Smart Sensor (Auto Ambient Brightness Sensor, Human Detection Sensor)
- Windows Hello

Software
Operating System: Support Windows 10, Windows 11

Accessories
In the Box:
- Monitor with stand
- 1x DP 1.4 cable (1.8m)
- 1x USB-C to USB-C Gen 1 cable (1.8m)
- 1x Power cable (1.8m)
- Quick setup guide

Model Information
Model: 64B7UAT1EU
Machine Type: 64B7
Region: EMEA
EAN / UPC / JAN: 0198157459489 / 198157459489 / None
