Display
Screen Size: 23.8 inch
Active Display Area: 527.04 (H) mm × 296.46 (V) mm
Resolution: 1920 × 1080
Backlight: E-LED
Pixel Pitch: 0.2745 (H) mm × 0.2745 (V) mm
Brightness: 250 cd/m²
Viewing Angle: 178° (H) / 178° (V)
Color Depth: 8 bit, 16.7 M
Contrast Ratio: 4000 : 1
Response Time: 7ms
Refresh Rate: Typ. 60 Hz, Max. 100Hz
Haze: Haze 25%
Reliability: 7 × 16 H
Color Gamut: 72% NTSC

Interface
Video & Audio Input: HDMI 1.4 × 1, VGA × 1
Video & Audio Output: Audio Out × 1
Data Transmission Interface: None
Control Interface: None

Power
Power Supply: DC 12V, 2.0A
Power Consumption: ≤ 24 W
Standby Consumption: ≤ 0.5 W

Working Environment
Working Temperature: 0℃ to 40 ℃ (32 ℉ to 104 ℉)
Working Humidity: 20% to 90% RH (Non-Condensing)
Storage Temperature: -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
Storage Humidity: 10% to 90% RH (Non-Condensing)

General
Casing Material: Plastic
VESA: 75 mm × 75 mm (4 - M4 × 6 mm)
Bezel Width: 2.0 mm (top/left/right), 23.55 mm (bottom)
Product Dimensions (W × H × D):
With base: 539.7 (W) mm × 427.33 (H) mm × 185.69(D) mm
21.25 (W) inch × 16.82 (H) inch × 7.31 (D) inch
Without base: 539.7 (W) mm × 327.33 (H) mm × 43.5 (D) mm
21.25 (W) inch × 12.89 (H) inch × 1.71 (D) inch
Package Dimensions (W × H × D):
611 (W) mm × 405 (H) mm × 118 (D) mm
(24.06(W) × 15.94(H) × 4.65 (D) ) inch
Net Weight: 2.85 ± 0.5 kg
Gross Weight: 3.85 ± 0.5 kg
Packing List:
Monitor × 1
Base component × 1
Power adapter (12 V, 2 A) × 1
HDMI cable (1.5 m) × 1
User manual × 1
Multilingual manual × 1
Remarks:
The base is included by default.
The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information.
