Model
Model No. : 238N01FIF
Size: 23.8"

Monitor Display Spec
Surface Treatment: Anti-Glare, Hard Coating (3H)
Curvature or Flat: Flat
Panel type (Display Mode): IPS panel
Brightness(Typical): 250 cd/m² (Max.)
Contrast(Typical): 1000:1
Color Pixel Pitch(mm): 0.2745(H) x 0.2745
Resolution (H x V): 1920 x 1080
Aspect Ratio: 16:9
Response Time (Typical): 4ms Typ
View Angles LR, UD (CR=10): 178°(H) /178°(V)
Display Colors: 16.7M
NTSC(Area): 72%

PC Input Range
Horizontal Freq: 53.7k - 90KHz
Vertical Freq: 48 to 76HZ
Max. display frequency (Resolution H x V/Fv): 1920 x 1080 75Hz for VGA, HDMI

Interface
Input 1 VGA: x 1
Input 2 DVI: No
Input 3 HDMI: HDMI 1.4 x 1
Input 4 DP: No
Input 5 USB: No
Output Type-C: Output 18W MAX
Input 6 Type-C: No
PBP / PIP: No
lifting base / revolving stand: No
Input Mini DP: No

Output Terminal
Earphone Jack: Yes
Speaker(Typical, Amplifier output): 4Ω 2W x 2

Power
Consumption(Typical): On: <48 W, Standby<=0.5W, Off<=0.5W
AC Power Range: 100-240V~, 50/60Hz
Power Mode: Adaptor 12V4A
Indicator Light: On Blue, Off: Red

Physical
Dimension with Stand(W x D x H): 537.85 x 170.10 x 396.89mm
Dimension with out Stand(W x D x H): 537.85 x 46.33 x 315.6mm
Dimension with Package(W x D x H): 593 x 108 x 375mm
Net Weight: 2.64kg
Gross Weight: 3.79kg
Tilt: -5° ~ 15° (+/-2°)
High Adjustable Arm: No
Swivel: No
Pivot: No
Kensington Lock: Yes
VESA Mounting: 75 x 75 (screw hole: 4 holes with M4 x 8 mm)

Function
Anti-flicker: Yes
Adaptive sync: Yes
G-Sync: Compliant
Free Sync: Compliant
Anti-Bluelight: Yes
HDR / DCR: No
Over Drive: Yes
Anti-glare: Yes
Daisy Chain: No

Controls
Back Control: Yes
On Screen Display: 14 Language: English / Italian / German / Spanish / Romanian / Hungarian / Czech / French / Portuguese / Bulgarian / Polish / Dutch / Slovak / Greek
Color: 6500, 7500, 9300, User
Preset Mode: GAME, MOVIE, PHOTO, STANDARD

Accessory
Power Adaptor: Adaptor x 1
Power Cord (1.5m): No
VGA Cable(1.5m): No
Audio Cable(1.8m): No
DVI Cable(1.5m): No
DP Cord(1.5m): No
HDMI Cable(1.5m): x 1
Quick Start Guide: No
Stands: Plastic central base
User Manual: x 1
