Model Number
Q500-WGNN-S00

Exterior Color
White

Materials - Exterior
Steel, Plastic, Tempered Glass

Materials - Left Side Panel
Grey TG + Steel

Dimensions (L x W x H)
406 x 231 x 415mm (Incl. Protrusions)
380 x 231 x 381mm (excl. Protrusions)

Volume
33.44L (excl. Protrusions)

Motherboard Support
ITX, Micro ATX, ATX, E-ATX (Width up to 296mm w/ SFX PSU, up to 273 w/ ATX PSU)

Expansion Slots
7

3.5" Drive Bays
4

2.5" Drive Bays
3

I/O Panel - USB Ports
2x USB 3.2 Gen 1 Type A
1x USB 3.2 Gen 2 x 2 Type C

I/O Panel - Audio In / Out
1x 3.5mm Combo

Pre-installed Fans - Rear
1x 120mm (1800 RPM) SF White PWM

Fan Support - Front
1x 120/140mm (x2 if PSU is mounted in bottom)

Fan Support - Top
2x 120/140mm

Fan Support - Rear
1x 120mm

Fan Support - Bottom
2x 120/140mm

Fan Support - Left side
2x 120/140mm

Radiator Support - Front
120mm, 140mm, (240/280mm w/ PSU in bottom)

Radiator Support - Top
120mm, 140mm, 240mm, 280mm, (280mm can be used within 53mm thickness)

Radiator Support - Rear
120mm

Radiator Support - Bottom
120mm
140mm
240mm
280mm

Radiator Support - Left side
120mm
140mm
240mm
280mm

Clearance - CPU Cooler
164mm-172mm (Remove the water cooling bracket)

Clearance - PSU
173mm to first GPU slot
216mm maximum space (w/o cable management space)
332mm space mounted in bottom (w/o cable management space)

Clearance - GFX
365mm

Cable Routing - Behind Motherboard Tray
29-32mm

Handle
Grey x 1

Gem Mini
Grey x 1

Dust Filters
Front, Top, Bottom, Right side

Power Supply Support
SFX, SFX-L, ATX

Series
QUBE Series

Size
Mid Tower
