Series
Elite Series

Size
Mid Tower

Model Number
E500-KN5N-S00 (Steel, ODD)

Color(s)
Black

Materials
Steel, Plastic, Tempered Glass

Dimensions (L x W x H)
464 x 204 x 455mm (incl Protrusions, ODD)
457 x 204 x 455mm (excl. Protrusions, ODD)

Volume
42.40L (exlc. Protrusions)

Motherboard Support
Mini ITX, Micro ATX, ATX

Expansion Slots
7

Kensington Lock
N/A

5.25" Drive Bays
1

2.5" / 3.5" Drive Bays (Combo)
2

2.5" Drive Bays
5

I/O Panel
2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)

Pre-installed Fans - Rear
1x 120mm

Fan Support - Top
2x 120mm, 2x 140mm

Fan Support - Front
2x 140mm, 3x 120mm (E500-KGNN-S00, E500-KNNN-S00), 2x 120mm (E500-KGNN-S00, E500-KNNN-S00), 3x 120mm (remove ODD bracket) (E500-KGNN-S00, E500-KNNN-S00)

Fan Support - Rear
1x 120mm

Radiator Support - Top
120 / 240mm (32mm max motherboard component height)

Radiator Support - Front
120mm, 140mm, 240mm, 280mm, 360mm (Remove ODD)

Radiator Support - Rear
120mm

Clearance - CPU Cooler
TG: 161mm, Steel: 163mm

Clearance - PSU
160mm (E500-KGNN-S00, E500-KNNN-S00), 180mm (E500-KG5N-S00, E500-KN5N-S00)

Clearance - GFX
400mm (w/o front fans & radiator)

Cable Routing
18.5mm

Dust Filters
Front, Top, Bottom

Power Supply Support
Bottom Mount, ATX
