Sleek design without compromise on performance and functionality.
The front slide panel hides your I/O ports, but keeps it easy to access when needed. The partial meshed front and ventilation holes on the side and top of the chassis generates plenty of airflow.
The MasterBox E500L will be available in three models with a different color accent. You can decide your personal preference and match the overall color theme of your build.
Show off this build in style through the edge to edge transparent acrylic side panel.

Features:
- Front Slide Panel: Keep a clean design and hide your I/O ports behind this smooth front slide panel.
- Colored trim: Stand out from the rest with a nice color accent.
- Support for a Total of 3 Fans & Watercooling: Three 120mm fans and front and rear watercooling support ensure that you don’t have to compromise on performance.
- Graphics card support up to 399mm: You won't ever have to worry about the fit of your graphics card, with support for even the largest, widest cards.

Product Number
MCB-E500L-KN5N-S02

Product Name
MasterBox E500L

Available Color
Black

Color of Trim
Silver

Materials
Steel, Plastic

Dimensions (LxWxH)
490 x 215 x 426mm

Motherboard Support
ATX (up to 272mm width) , Micro-ATX, Mini-ITX

Expansion Slots
7

Drive Bays
5.25" 1
3.5" HDD 2
2.5” SSD 2

I/O Port
USB 3.0 x 2, Audio In / Out

Pre-installed Fan
Rear 120mm x 1 black fan

Fan Support
Front 120/140mm x 2
Top 120mm x 2**
Rear 120mm x 1

Radiator Support
Front 120 / 140 / 240 / 280mm radiator
Rear 120mm radiator (Need to install fan first)

Clearances
CPU cooler 172mm
PSU 220mm
GPU 399mm

Cable Routing
Behind 22mm
MB Tray

Dust Filters
Front, Top, Bottom

Power Supply Support
Bottom mount, ATX

Carton dimension (L x W x H)
470 x 227 x 555mm*

Part Number
MCB-E500L-KN5N-S02

EAN Code
4719512070086

UPC Code
884102042591

Net weight
4.425 Kg

Gross weight
5.26 Kg
