MODEL NUMBER: MCB-D500D-KGNN-S01, MCB-D500D-KGNN-S00, MCB-D500D-WGNN-S01, MCB-D500D-WGNN-S00

SERIES: MasterBox Series

SIZE: Mid Tower

AVAILABLE COLOR(S): Black, White

MATERIALS: Steel, Plastic, Tempered Glass, Mesh

DIMENSIONS (L X W X H): 493 x 217 x 469mm (incl. Protrusions), 429.5 x 205x 447mm (excl. Protrusions)

WEIGHT: 6.95 kg

MOTHERBOARD SUPPORT: Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*support for up to 12" x 10.7", will limit cable management features)

EXPANSION SLOTS: 7

5.25" DRIVE BAYS: N/A

2.5" / 3.5" DRIVE BAYS (COMBO): 2

2.5" DRIVE BAYS: 4 (2+2 combo)

I/O PANEL: 2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB Controller (only for the S01 versions), 1x ARGB 2-to-3 splitter

PRE-INSTALLED FANS - TOP: N/A

PRE-INSTALLED FANS - FRONT: 3x 120mm ARGB Fans

PRE-INSTALLED FANS - REAR: N/A

FAN SUPPORT - TOP: 3x 120mm, 2x 140mm

FAN SUPPORT - FRONT: 3x 120mm, 2x 140mm

FAN SUPPORT - REAR:1x 120mm

RADIATOR SUPPORT - TOP: 120mm, 240mm, 360mm, (44mm max motherboard component height)

RADIATOR SUPPORT - FRONT: 120mm, 140mm, 240mm, 280mm, 360mm

RADIATOR SUPPORT - REAR: 120mm

CLEARANCE - CPU COOLER: 165mm/6.49"

CLEARANCE - PSU: 180mm/7.08", 295mm/11.61" (w/ HDD cage removed)

CLEARANCE - GFX: 410mm/16.1"

CABLE ROUTING: 19mm/0.74"

DUST FILTERS: Top, Bottom, Front

POWER SUPPLY SUPPORT: Bottom mount, ATX

WARRANTY: 2 years

EAN CODE: 4719512095522 (Mesh w/ controller), 4719512095515 (Mesh w/o controller), 4719512095546 (Mesh White w/ controller), 4719512095539 (Mesh White w/o controller)

UPC CODE: 884102067822 (Mesh w/ controller), 884102067815 (Mesh w/o controller), 884102067846 (Mesh White w/ controller), 884102067839 (Mesh White w/o controller)
