Product Name
ELITE 502

Model Number
E502-KGNN-S00

Color
Black

Materials
Exterior: Steel
Right Side Panel: Steel
Left Side Panel: TG

Dimensions (L x W x H)
474 x 230 x 481 mm(Incl. Protrusions)
435 x 230 x 465 mm(Excl. Protrusions)

Volume (incl. Protrusions)
49.73 L

Motherboard Support
ITX
Micro ATX
ATX (Supporting Back-connector Motherboard)
E-ATX
Up to 30.5cm x 27.7cm motherboards, may impact cable management

Expansion Slots
7

5.25" Drive Bays
N/A

3.5" Drive Bays
2

2.5" Drive Bays
2 (Max.6)

I/O Panel - USB Ports
1x USB 3.2 Gen1 Type A
1x USB 3.2 Gen1 Type C

I/O Panel - Audio In / Out
3.5 mm Combo x 1

Fan Support - Front
(Filtered) 140 mm x 3 / 120 mm x 3

Fan Support - Top
(Filtered) 140 mm x 2 / 120 mm x 3

Fan Support - Rear
1x 120mm

Pre-installed Fans - Front
3x 120mm ARGB Fans

Pre-installed Fans - Top
N/A

Pre-installed Fans - Rear
N/A

Radiator Support - Front
120 / 140 / 240 / 280 / 360 / 420 mm (Limit: 457*140*27 mm)

Radiator Support - Top
120 / 140 / 240 / 280 / 360mm

Radiator Support - Rear
120mm

Clearance - CPU Cooler
170mm

Clearance - PSU
170mm, 210mm (w/o HDD Cage)

Clearance - Graphics Card (installed 3.5"HDD BRK)
360 / 410 mm (w/o front radiator)

Cable Routing - Behind Motherboard Tray
33-35 mm

Dust Filters
Top, Front, Bottom

Power Supply Support
ATX

Series
Elite Series

Size
Mid Tower
