Specifications
Model number: MasterBox 600 Lite Black MB600L-KGNN-S00
Exterior color: Black
Materials exterior: Steel, Plastic
Materials side panel: Tempered glass
Dimensions (L x W x H): 474 x 230 x 481 mm (incl. protrusions), 465 x 230 x 465 mm (excl. protrusions)
Volume: 49.73 L
Motherboard support: ITX / Micro ATX / ATX (supporting back-connector motherboard) / E-ATX (up to 12" x 10.9" / 30.5 x 27.7 cm, may impact cable management)
Back connector motherboard support: Yes
Expansion slots: 7
3.5" drive bays: 2
2.5" drive bays: 2 (max. 6)
I/O panel USB ports: 1 x USB 3.2 Gen 1 Type-A, 1 x USB 3.2 Gen 1 Type-C
I/O panel audio in / out: 1 x 3.5 mm combo
Fan support front: 3 x 120 / 140 mm
Fan support top: 3 x 120 mm / 2 x 140 mm
Fan support rear: 1 x 120 mm
Radiator support front: 120 / 140 / 240 / 280 / 360 / 420 mm (limit 457 x 140 x 27 mm)
Radiator support top: 120 / 140 / 240 / 280 / 360 mm
Radiator support rear: 120 mm
Clearance CPU cooler: 170 mm
Clearance PSU: 170 mm, 210 mm (without HDD cage)
Clearance GFX: 360 mm, 410 mm (without front radiator)
Cable routing behind motherboard tray: 33–35 mm
Dust filters: Top, Bottom
Power supply support: ATX
Size: Mid tower
Series: MasterBox series
