Product name
Product name: QUBE 540

Color
Moonstone

Material
Exterior: STEEL
Side Panel (Right): STEEL
Side Panel (Left): TG

Dimension (L x W x H)
Incl. Protrusions: 438.5 x 225 x 492.1 mm
Excl. Protrusions: 425 x 225 x 425 mm
Volume (w/o protrusions): 40.64 L
Volume (with panel, protrusions and feet): 48.55 L

Motherboard support
Motherboard Support: ITX / M-ATX / ATX / E-ATX (Up to 280 mm)

Expansion Slots
7

Drive bays
5.25’’ ODD: N/A
3.5’’ HDD: 1 (Shared 3.5" and 2.5" mounting on PSU bracket)
2.5’’ SSD: 2 (Max. 5)

IO panel
USB Ports: 2 x USB 3.2 Gen 1 Type A / 1 x USB 3.2 Gen 2 x 2 Type C
Audio In / Out 3.5 mm: 1 x 3.5Mic / Audio Combo Jack

Fan support
Front: 3 x 120 mm (w/o I/O panel) / 2 x 140 mm
Top: 3 x 120 mm (w/o I/O panel) / 2 x 140 mm
Rear: 1 x 120 mm
Bottom: 3 x 120 mm / 2 x 140 mm

Preinstalled fan(s)
Front: N/A
Top: N/A
Rear: 1x 120mm Black

Radiator support
Front: 140 / 280 / 360 mm (w/o I/O panel)
Top: 140 / 280 / 360 mm (w/o I/O panel)
Rear: 120 mm
Bottom: 140 / 280 / 360mm (w/o I/O panel)

Clearances
CPU Cooler: 172 mm
Power Supply: 200 mm
Graphics Card: 415 mm (w/o Front Fan)
Cable Routing Behind MB Tray: 27 mm

Dust Filters: Top, Bottom, Front
Power Supply Support: ATX/ SFX
