Product Information
Product Name: Elite 600
Notes: Series Elite Series
Color: Black

Materials
Exterior: SPCC
Side Panel (Left / Right): Tempered Glass / Steel

Dimension (L x W x H)
Incl. Protrusions: 445 x 285 x 410mm
Excl. Protrusions: 445 x 285 x 400 mm

Volume
Volume: 50.73 L No Protrusions

Hardware support
Motherboard Support: Mini-ITX, Mini-DTX, Micro-ATX, ATX
Power Supply Support: ATX
PCI Expansion Slots: 7

Storage Support
5.25" Drive Bays: 0
3.5" Drive Bays: 1
2.5" / 3.5" Drive Bays: 1
2.5" Drive Bays: 2

I/O Panel
USB Ports: 2x USB 3.1 Gen 1 Type-A, 1x USB 3.2 Gen 2x2 Type-C
Audio In / Out: 1x 3.5mm Headset Jack (Audio+Mic)

Preinstalled Fan
Top: N/A
Rear: 1x 120mm
Side mount: 3x 120mm reverse version

Fans Support
Bottom: 3x 120mm
Top: 3x 120mm, 2x 140mm
Rear: 1x 120mm
Side: 3x 120mm, 2x 140mm

Radiator Support
Bottom: 240 / 360 mm
Top: 240 / 280 / 360 mm
Rear: 120 mm
Side: 240 / 280 mm

Dust Filters
Removable Filters: Top, Bottom, Right side panel

Clearances
CPU Cooler: 160 mm
Power Supply: 240 mm
Graphics Card: L: 425 mm (incl. power connector) H: 160 mm (incl. power connector)

Additionals
Included Accessories: N/A
Cable Routing Behind MB Tray: 11 mm
