GPU
512 Stream Processors
14 nm FinFET
4th Graphics Core Next (GCN)
1206 MHz Boost Engine Clock

Memory
128 bit Memory Bus
GDDR5 Memory Type
1500 MHz, 6000 MHz Effective
4 GB Size

BIOS Support
UEFI BIOS

Displays
Maximum 3 Outputs

Output
1 x DVI-D
1 x HDMI
1 x DisplayPort 1.4

Resolution
5120?880 (60Hz) Pixel DisplayPort Resolution
2560x1600 (60Hz) Pixel Dual Link DVI Resolution
4096?160 (60 Hz) HDMI Resolution

API
OpenGL® 4.5
OpenCL 2.0
DirectX® 12
Shader Model 5.0

Feature FreeSync Technology
AMD Eyefinity
AMD Xconnect ready
DirectX™ 12 Optimized

HDR Ready
Frame Rate Target Control
Intelligent Fan Control III
Radeon Chill
Radeon Relive

Cooling
Single fan

Form Factor
1.5 Part Slot Occupied
158(L)X 112(W)X 28 (H) Dimension /mm

Power Consumption
<65W

OS
Windows 10&#12288;
Windows 7&#12288;

System Requirement
400 Watt Power Supply (Suggestion)
Blue-ray™ / HD DVD playback requires Blu-ray / HD DVD drive.
PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with.
