GPU engine specs
CUDA Cores: 8960
Boost Clock (MHz): 2452MHz
Base Clock (MHz): 2295MHz

Thermal and power spec
Minimum System Power Requirement (W): 750W
Supplementary Power Connectors: 2x PCIe 8-pin cables (adapter in box) OR 300 W or greater PCIe Gen 5 cable

Memory specs
Memory Clock: 28Gbps
Standard Memory Config: 16GB
Memory Interface: GDDR7
Memory Interface Width: 256-bit
Memory Bandwidth (GB/sec): 896 GB/sec

Feature support
Real-Time Ray Tracing: Yes
Ray Tracing Cores: 4th Generation, 133 TFLOPS
Tensor Cores: 5th Generation, 1406 AI TOPS
NVIDIA Architecture: Blackwell
Microsoft DirectX: 12 Ultimate
NVIDIA DLSS: 4
NVIDIA Ansel: Yes
NVIDIA FreeStyle: Yes

Bus support
Bus Support: PCI Express Gen 5

Software features
NVIDIA ShadowPlay: Yes
OS Certification: Windows 11, Linux, FreeBSDx86
NVIDIA Highlights: Yes
NVIDIA G-SYNC-Ready: Yes
Game Ready Drivers: Yes
NVIDIA Studio Drivers: Yes
NVIDIA GPU Boost: Yes
Vulkan API: 1.4
OpenGL: 4.6
NVIDIA Encoder: 2x Ninth Generation
NVIDIA Decoder: 1x Sixth Generation

Accessories
Graphics Card Dimensions:
Length: 300mm
Height: 116mm
Width: 41mm

Display support
Multi Monitor: up to 4
Maxmium Digital Resolution: 4K at 480Hz or 8K at 165Hz with DSC
HDCP: 2.3
Standard Display Connectors: 3x DisplayPort 2.1b, 1x HDMI 2.1b
