Model
MPE-7502-ACAAG

ATX Version
ATX 12V Ver. 3.1

PFC
Active PFC

Input Voltage
100-240V

Input Current
10-6A

Input Frequency
50-60Hz

Dimensions (L x W x H)
140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch

Fan Size
120mm

Fan Bearing
HDB

Efficiency
≥90% @ Typical Load

80 PLUS Rating
80 PLUS Gold

ErP 2014 Lot 3
Yes

Operating Temperature
0-40°C

Power Good Signal
100 - 150 ms

Hold Up Time
>16ms

MTBF
>100,000 Hours

Protections
UVP
OVP
OPP
OTP
SCP
OCP

Regulatory
cTUVus
TUV
CE
FCC
BSMI
CCC
EAC
RCM
UKCA
RoHS2.0 / BIS
KC

ATX 24 Pin Connectors
1

EPS 8 Pin / 4+4 Pin Connectors
2

SATA Connectors
6

Peripheral 4 Pin Connectors
3

PCI-e 6+2 Pin Connectors
4

Series
G Series

80 Plus Efficiency
Gold

Modular
Non Modular

Category
500 to 750W

Form Factor
ATX

Watts
750W
