PFC
Active PFC

ErP 2014 Lot 3
Yes

Input Frequency
50-60Hz

ATX 24 Pin Connectors
1

EPS 4+4 Pin Connectors
1

Fan Size
120mm

Power Good Signal
100 - 500 ms

MTBF
>100,000 Hours

Modular
Non Modular

Fan Bearing
HDB

Efficiency
85% Typically

80 Plus Efficiency
White

80 PLUS Rating
80 PLUS Standard 230V EU

Operating Temperature
40°C

PCI-e 6+2 Pin Connectors
2

SATA Connectors
6

Fan Speed
1500 RPM

ATX Version
ATX 12V V2.52

Protections
OVP
OPP
SCP
UVP
OTP

Peripheral 4 Pin Connectors
3

Input Current
5A

Series
MWE White Series

Hold Up Time
>14ms at 100% Full Load@230Vac

Dimensions (L x W x H)
140 x 150 x 86 mm

Noise Level @ 100%
31.2 dBA

Noise Level @ 50%
18.4 dBA

Input Voltage
200-240Vac

Noise Level @ 20%
13.8 dBA

Regulatory
CCC
CE
TUV-RH
RCM
EAC
cTUVus
FCC
BSMI
KC
CB

Model
MPE-5501-ACABW
