ATX Version
ATX 12V Ver. 3.0

PFC
Active PFC

Input Voltage
100-240V

Input Current
10-5A

Input Frequency
50-60Hz

Dimensions (L x W x H)
160 x 150 x 86 mm

Fan Size
120mm

Fan Bearing
HDB

Fan Speed
2500 RPM

Efficiency
≥90% @ Typical Load

80 PLUS Rating
80 PLUS Gold

ErP 2014 Lot 3
Yes

Operating Temperature
0-40°C

Power Good Signal
100 - 150 ms

Hold Up Time
≥16ms at 80% Load

MTBF
>100,000 Hours

Protections
OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection

Regulatory
cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region's requests.)

ATX 24 Pin Connectors
1

EPS 4+4 Pin Connectors
1

EPS 8 Pin Connector
1

SATA Connectors
6

Peripheral 4 Pin Connectors
2

PCI-e 6+2 Pin Connectors
4

12VHPWR Connector
1

Series
GX Series

80 Plus Efficiency
Gold

Modular
Fully Modular

Category
Above 750W

Form Factor
ATX

Watts
750W
