1500
750
• Voltage: 162-290V
• Frequency: 50Hz±5%
• Voltage: 220V(±10%) [AC] / 220V(±7%) [INV]
• Frequency: 50Hz (±1%)
• AVR: Built-in
• Waveform: Pure SineWave
Less than 2-6 ms (typical), 10 Max
Total Efficiency Over 80%
• Voltage 24VDC
• Capacity 12V/7.2Ah
• Quantity 2
• Recharge Time 6 hours to (90%)
• Type Sealed Maintenance Free
Lead Acid VRLA Type

Input Voltage, Output Voltage, Load Level Indicator, Overload,
Utility Normal, Backup, Battery Low and Battery Fault conditions
• Overload AC Buzzer continuously alarms then UPS shuts
down after 10 seconds (>110%)
• Overload Inverter UPS shuts down after 10 seconds (>110%)
• Short Circuit INV Input Fuse & Electric Circuit
• Short Circuit AC Electric Circuit
• Battery Over-drain Two stages: Controlled Battery
Low Warning & Cut Off
• Modem (RJ11) & LAN (RJ45)
• Spike Suppression Meets EN61000-4-5
• Noise Suppression Meets EN50991-1
• Battery Mode (sound every 10 seconds)
• Low Battery (sound every seconds)
• OverLoad (sound every 0.5 seconds)
• Battery Replacement Alarm (sound every 2 seconds)
• Fault (continuously sounding)

• Output 2xIEC (Battery Power Supplied)
• Output 2xSchuko (Battery Power Supplied)
• Computer USB
Less than 45dB
10 to 30 mins for typical PC Load
146 x 160 x 350 mm
9.0 Kg (with Battery)
• Temperature 0°-40° C
• Humidity 0-95% (non-condensing)
