Power Rating (VA): 1200
Power Rating (W): 720

Input:
- Voltage: 170-280VAC
- Frequency: 50Hz±5%

Output
- Voltage: 230VAC(±10%) [AC] / 230VAC(±7%) [INV]
- Frequency: 50Hz (±1%)
- AVR: Built-in
- Waveform: Pure SineWave
Transfer: 4ms typical, 10ms max

Efficiency:
- Line Mode: >95% (50%- AVR: >88% (50%- Battery Mode: >70% (25%
Battery
- Voltage: 24VDC
- Capacity: 12V/7.0Ah
- Quantity: 2
- Recharge Time: 8 hours to (90%)
- Type: Sealed Maintenance Free Lead Acid VRLA Type
- Design: Easy-swappable battery design
- Charging Voltage: 27,4VDC ±1%
- Charging: 1.0A Max

Indicators LCD Display
- Input Voltage, Output Voltage, Load Level Indicator, Overload, Utility Normal, Backup, Battery Low and Battery Fault conditions

Protection:
- Overload AC Buzzer continuously alarms then UPS shuts down  after 5 minutes (>110%±10%)
- Overload Inverter UPS shuts down immediately and go to Fault (>120%±10%)
- Overload Battery Buzzer continuously alarms then UPS shuts down after 5 seconds (>110%±10%)
- Overload Battery UPS shuts down immediately (>120%±10%)
- Short Circuit INV (ICB) & Electric Circuit
- Short Circuit AC Electric Circuit
- Battery Over-drain Two stages: Controlled Battery Low  Warning & Cut Off

Alarm:
- Battery Mode (sound every 10 seconds)
- Low Battery (sound every  seconds)
- OverLoad (sound every  0.5 seconds)
- Battery Replacement Alarm
- Fault (sounding)

Connections:
- Output 6xIEC 320 C13 (Battery  Power Supplied)
- USB
- Intelligent Slot for SNMP Card (A03-SNMP1-IN)

Noise Level: Less than 40dB (No FAN)
Backup Time (min):
- 100% (720W) up to 2:00m
- 80% (576W) up to 2:50m
- 60% (432W) up to 6:20m
- 40% (288W) up to 11:00m

Dimensions (WxHxD): 438 x 88 (2U) x 310 mm
Weight 11,0 Kg (with battery)
Temperature: 0°-40° C
Humidity: 0-90% (non-condensing)
