Model
DVB4224GL

Processor
MT7628DA

Internal memory
128MB

2.4G Wi-Fi
2x2

5G Wi-Fi
2x2

Antennas
4 external omnidirectional antennas

Total interfaces
Two 10/100M self-adaptive LAN ports (Auto MDI/MDIX) / One 10/100M self-adaptive WAN port (Auto MDI/MDIX)

LED indicator lights
2

Protocol standards
IEEE 802.11a/b/g/n/ac, IEEE 802.3/3u

Dual band
2.4GHz and 5GHz

Modulation
11b: DSSS: DBPSK (1Mbps), DQPSK (2Mbps), CCK (5.5/11Mbps) / 11a/g: OFDM: BPSK (6/9Mbps), QPSK (12/18Mbps), 16QAM (24/36Mbps), 64QAM (48/54Mbps) / 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM. Rate set: MCS0 to MCS15 / 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM. / Rate set: MCS0 to MCS9 (supports 2 streams)

Operating system
Mi Wi-Fi ROM intelligent router operating system based on a highly customized version of OpenWRT

Wireless security
WPA-PSK/WPA-PSK2 encryption, wireless access control (blacklist and whitelist), SSID hiding, smart unauthorized access prevention

Management application
Supports web, iOS, and Android

Wi-Fi
1167 Mbps

LAN
1000 Mbps
