General
Category: Cat 6
Length: 1m
Operating Voltage: 57V

Conductor
Conductor Material: Bare Copper (99.95%)
Conductor Diameter: 7 x 0.2mm 24AWG

Insulation
Insulation Material: HDPE

Sheath
Sheath Material: PVC
Sheath Thickness: 0.50 ± 0.05mm
Sheath Diameter: 5.8 ± 0.20 mm
Sheath Color: Gray

Plug
Plug Material: PC UL94V-0
Gold Plating: 30u inch

Electrical Characteristic
Impedance: 100±15 Ω
DC Resistance: ≤ 9.4 Ω/100 m
